Backups are essential for ensuring data security. In this guide, I will walk you through setting up Restic, a fast and secure backup tool, to work with Wasabi S3-compatible storage on Debian 12 Bullseye.
This tutorial uses the Wasabi region Osaka (ap-northeast-2) and a bucket named bucket-osaka-sandbox.
We will organize backups using subdirectories and tags for each virtual machine.
Step 1.1 : Install Restic
First, install Restic using the package manager.
sudo apt update
sudo apt install restic -y
Verify the installation:
restic version
Step 1.2 : Install AWS CLI
Next, install AWS CLI using the package manager.
sudo apt update
sudo apt install aws-cli -y
Setup the access key and secret key using value from Wasabi:
aws configure
Step 2: Set Up Environment Files
Create a directory to store Restic configuration files:
sudo mkdir -p /etc/restic.d
sudo chmod 700 /etc/restic.d
2.1 Create the .restic-env File
This file stores environment variables for Restic. Use the following template:
sudo vi /etc/restic.d/.restic-env
Add the following content:
SERVER_NAME=vm-osaka-1
LOCAL_REPOSITORY=/var/app
AWS_ACCESS_KEY_ID=your_wasabi_access_key
AWS_SECRET_ACCESS_KEY=your_wasabi_secret_key
RESTIC_REPOSITORY=s3:https://s3.ap-northeast-2.wasabisys.com/bucket-osaka-sandbox
Replace your_wasabi_access_key and your_wasabi_secret_key with your Wasabi credentials.
Secure the file:
sudo chmod 600 /etc/restic.d/.restic-env
2.2 Create the .restic-password File
This file stores the encryption password for your backups.
sudo vi /etc/restic.d/.restic-password
Add a strong password:
your_secure_password
Secure the file:
sudo chmod 600 /etc/restic.d/.restic-password
Step 3: Create the Restic Script
Next, create a bash script to handle Restic operations.
sudo vi /etc/restic.d/.restic.sh
Add the following content:
#!/bin/bash
source /etc/restic.d/.restic-env
# Option 0 - Change password
#restic -r "$RESTIC_REPOSITORY/$SERVER_NAME" key passwd
# Option 1 - Init repository
#restic -r "$RESTIC_REPOSITORY/$SERVER_NAME" init --password-file "/var/app/secret/.restic-password"
# Option 2 - Backup
restic -r "$RESTIC_REPOSITORY/$SERVER_NAME" backup "$LOCAL_REPOSITORY" --tag "$SERVER_NAME" --password-file "/etc/restic.d/.restic-password" --verbose
# Option 3 - List snapshots
restic -r "$RESTIC_REPOSITORY/$SERVER_NAME" snapshots --password-file "/etc/restic.d/.restic-password" --verbose
# Option 4 - Housekeeping
restic -r "$RESTIC_REPOSITORY/$SERVER_NAME" forget --keep-last 7 --keep-daily 7 --keep-weekly 4 --keep-monthly 6 --prune --password-file "/etc/restic.d/.restic-password" --verbose
Make the script executable:
sudo chmod +x /etc/restic.d/.restic.sh
Step 4: Initialize the Restic Repository
Run the script to initialize the repository.
sudo bash /etc/restic.d/.restic.sh
Uncomment the Init repository line in the script (Option 1) and re-run the script to initialize:
restic -r "$RESTIC_REPOSITORY/$SERVER_NAME" init --password-file "/var/app/secret/.restic-password"
Step 5: Perform a Backup
To perform a backup, ensure the Backup section (Option 2) in the script is uncommented, then execute:
sudo bash /etc/restic.d/.restic.sh
The backup will store data from /var/app to s3://bucket-osaka-sandbox/vm-osaka-1 with the tag vm-osaka-1.
Step 6: List Snapshots
To list snapshots, uncomment the List snapshots line (Option 3) and run the script:
sudo bash /etc/restic.d/.restic.sh
Step 7: Perform Housekeeping
Housekeeping removes old backups and optimizes the repository. Uncomment the Housekeeping line (Option 4) and run the script:
sudo bash /etc/restic.d/.restic.sh
This setup keeps:
- Last 7 snapshots
- 7 daily snapshots
- 4 weekly snapshots
- 6 monthly snapshots
Step 8: Automate Backups with Systemd
To schedule backups, create a systemd service and timer.
Create the Systemd Service
sudo vi /etc/systemd/system/restic-backup.service
Add the following:
[Unit]
Description=Restic Backup Service
Wants=restic-backup.timer
[Service]
Type=oneshot
ExecStart=/bin/bash /etc/restic.d/.restic.sh
Create the Systemd Timer
sudo vi /etc/systemd/system/restic-backup.timer
Add the following:
[Unit]
Description=Run Restic Backup Daily
[Timer]
OnCalendar=*-*-* 02:00:00
Persistent=true
[Install]
WantedBy=timers.target
Enable and start the timer:
sudo systemctl enable restic-backup.timer
sudo systemctl start restic-backup.timer
Summary
With this setup, Restic will securely back up your files to Wasabi S3 storage. The use of subdirectories and tags makes it easy to manage backups for multiple virtual machines.
Automating the process with systemd ensures your data remains secure with minimal effort.
